Place of Origin:
China
Brand Name:
SUNPOK
Certification:
CE TUV Rohs
Model Number:
NES144-6-450M
Embrace the power of the sun with Sunpok Solar Panels – the ultimate solution for sustainable energy generation. Meticulously engineered with cutting-edge technology and unwavering commitment to excellence, our solar panels are designed to redefine the way you power your life.
Efficiency Redefined:
Sunpok Solar Panels are built to maximize energy conversion, ensuring you get the most out of every ray of sunlight. With advanced photovoltaic technology and superior craftsmanship, our panels deliver unmatched efficiency and performance, providing you with a reliable and consistent source of clean energy.
Tailored Solutions for Every Need:
Whether you're looking to power your home, business, or industrial facility, Sunpok Solar Panels offer tailored solutions to fit your unique energy requirements. From sleek rooftop installations to ground-mounted arrays, our versatile panels seamlessly integrate into any environment, providing you with a seamless and efficient energy solution.
Reliability You Can Trust:
Backed by years of industry expertise and rigorous testing, Sunpok Solar Panels are built to last. Our panels are designed to withstand the elements and deliver reliable performance year after year, ensuring peace of mind and energy independence for you and your family.
Sustainability at Its Core:
At Sunpok, we're committed to sustainability and environmental responsibility. By harnessing the power of the sun, our solar panels help reduce reliance on fossil fuels and minimize carbon emissions, contributing to a cleaner, greener future for generations to come.
Experience the Sunpok Difference:
Ready to make the switch to clean, renewable energy? Experience the Sunpok difference with our high-quality solar panels and take the first step towards a brighter, more sustainable future. Contact us today to learn more about our solar panel products and start harnessing the power of the sun with Sunpok.
Main Parameters of Sunpok Mono PV Panels
| Electrical Characteristics | |||
| Model | NES144-6-450M | NES132-7-500M | NES144-7-550M |
| Maximum Power(Pmax) | 450W | 500W | 550W |
| Optimum Operating Voltage(Vmp) | 41.00V | 38.35V | 41.96V |
| Optimum Operating Current(Imp) | 10.98A | 13.04A | 13.11A |
| Open Circuit Voltage(Voc) | 49.50V | 45.59V | 49.90V |
| Short Circuit Current(Isc) | 11.42A | 13.93A | 14.00A |
| Module Efficiency | 20.70% | 20.37% | 21.28% |
| Operating Module Temperature | -40 ℃ to +85 ℃ | ||
| Maximum System Voltage | 1500V DC (IEC) | ||
| Power Tolerance | 0~+5W | ||
| STC | irradiance 1000 W/m2, module temperature 25oC, AM=1.5; Best in Class AAA solar simulator (IEC 60904-9) used | ||
| Mechanical Characteristics | |||
| Solar Cell | 166mm 9BB Monocrystalline silicon cells | ||
| No. of Cells | 144(6x12x2) | ||
| Dimensions | 2094x1038x35mm；2108x1048x35mm | ||
| Weight | 24.5kg | ||
| Front Glass | 3.2mm(0.13 inches) tempered glass | ||
| Frame | Anodized aluminum alloy | ||
| Junction Box | Ip67 rated | ||
| Output Cables | 4.0 mm 2 (0.006 inches 2 ), 300mm/Customized | ||
| Connectors | MC4 connectors | ||
| Temperature Characteristics | |||
| NOCT | 45±2 ℃ | ||
| Temperature Coefficient of Pmax | -0.380%/ ℃ | ||
| Temperature Coefficient of Voc | -0.300%/ ℃ | ||
| Temperature Coefficient of Isc | 0.060%/ ℃ | ||
| Packing Configuration(35mm) | |||
| Per Pallet | 30Pieces | ||
| Per Container (20' GP) | 282Pieces | ||
| Per Container (40' HQ) | 704Pieces | ||
Sunpok Mono PV Panels Production Plant and Packaging
FAQ
Question 1: What is the lead time?
Answer 1: We can deliver within 3-15 days.
Question 2: What is the warranty period, and how many years?
Answer 2: The warranty period for mono PV panels is 10-25 years.
Question 3: How is your technical support?
Answer 3: We provide lifetime online support through Whatsapp/ Skype/ Wechat/ Email. Any problem after delivery, we will offer you a video call anytime, our engineer will also go to overseas help our customers if necessary.
Question 4: How to become your agent?
Answer 4: Contact us through the website, email, or phone, and we can talk about details to confirm.
Question 5: Is the sample available and free?
Answer 5: Sample will be charged a cost, but the cost will be refunded after the bulk order.
Question 6: Do you support OEM/ODM?
Answer 6: Of course, we can do customized services for our partners.
If you have other questions, please add the contact information of our sales manager to understand, thank you!
