Place of Origin:
China
Brand Name:
SUNPOK
Certification:
CE TUV Rohs
Model Number:
NES144-6-450M
Elevate your home or business to new heights of sustainability with Sunpok Solar Panels. Crafted with precision engineering and cutting-edge technology, our solar panels are your gateway to clean, renewable energy.
Efficiency and Reliability Combined:
Sunpok Solar Panels are designed to harness the sun's abundant energy with maximum efficiency and reliability. Our advanced photovoltaic cells ensure optimal energy conversion, providing you with a consistent and dependable power supply day after day, year after year.
Tailored Solutions for Every Need:
Whether you're looking to power your home, office, or industrial facility, Sunpok Solar Panels offer tailored solutions to fit your unique energy requirements. From sleek rooftop installations to ground-mounted arrays, our panels seamlessly integrate into any environment, delivering sustainable energy solutions that meet your needs.
Commitment to Sustainability:
At Sunpok, sustainability is more than just a goal – it's our mission. By choosing Sunpok Solar Panels, you're not just investing in clean energy; you're investing in a cleaner, greener future for generations to come. Join us in our commitment to reducing carbon emissions and preserving our planet for future generations.
Expert Support Every Step of the Way:
With Sunpok Solar Panels, you're not just getting top-of-the-line products – you're also getting expert support from start to finish. Our team of experienced professionals will guide you through the entire process, from initial consultation to installation and beyond, ensuring a seamless transition to clean, renewable energy.
Make the Switch to Solar with Sunpok:
Ready to take control of your energy future? Discover the power of solar with Sunpok Solar Panels and experience the benefits of sustainable energy firsthand. Contact us today to learn more about our solar panel products and start your journey towards a brighter, more sustainable future.
Main Parameters of Sunpok Mono PV Panels
| Electrical Characteristics | |||
| Model | NES144-6-450M | NES132-7-500M | NES144-7-550M |
| Maximum Power(Pmax) | 450W | 500W | 550W |
| Optimum Operating Voltage(Vmp) | 41.00V | 38.35V | 41.96V |
| Optimum Operating Current(Imp) | 10.98A | 13.04A | 13.11A |
| Open Circuit Voltage(Voc) | 49.50V | 45.59V | 49.90V |
| Short Circuit Current(Isc) | 11.42A | 13.93A | 14.00A |
| Module Efficiency | 20.70% | 20.37% | 21.28% |
| Operating Module Temperature | -40 ℃ to +85 ℃ | ||
| Maximum System Voltage | 1500V DC (IEC) | ||
| Power Tolerance | 0~+5W | ||
| STC | irradiance 1000 W/m2, module temperature 25oC, AM=1.5; Best in Class AAA solar simulator (IEC 60904-9) used | ||
| Mechanical Characteristics | |||
| Solar Cell | 166mm 9BB Monocrystalline silicon cells | ||
| No. of Cells | 144(6x12x2) | ||
| Dimensions | 2094x1038x35mm；2108x1048x35mm | ||
| Weight | 24.5kg | ||
| Front Glass | 3.2mm(0.13 inches) tempered glass | ||
| Frame | Anodized aluminum alloy | ||
| Junction Box | Ip67 rated | ||
| Output Cables | 4.0 mm 2 (0.006 inches 2 ), 300mm/Customized | ||
| Connectors | MC4 connectors | ||
| Temperature Characteristics | |||
| NOCT | 45±2 ℃ | ||
| Temperature Coefficient of Pmax | -0.380%/ ℃ | ||
| Temperature Coefficient of Voc | -0.300%/ ℃ | ||
| Temperature Coefficient of Isc | 0.060%/ ℃ | ||
| Packing Configuration(35mm) | |||
| Per Pallet | 30Pieces | ||
| Per Container (20' GP) | 282Pieces | ||
| Per Container (40' HQ) | 704Pieces | ||
Sunpok Mono PV Panels Production Plant and Packaging
FAQ
Question 1: What is the lead time?
Answer 1: We can deliver within 3-15 days.
Question 2: What is the warranty period, and how many years?
Answer 2: The warranty period for mono PV panels is 10-25 years.
Question 3: How is your technical support?
Answer 3: We provide lifetime online support through Whatsapp/ Skype/ Wechat/ Email. Any problem after delivery, we will offer you a video call anytime, our engineer will also go to overseas help our customers if necessary.
Question 4: How to become your agent?
Answer 4: Contact us through the website, email, or phone, and we can talk about details to confirm.
Question 5: Is the sample available and free?
Answer 5: Sample will be charged a cost, but the cost will be refunded after the bulk order.
Question 6: Do you support OEM/ODM?
Answer 6: Of course, we can do customized services for our partners.
If you have other questions, please add the contact information of our sales manager to understand, thank you!
