SUNPOK Inverter Three Phase With Mppt Solar Charge Controller Manufacturers 5kw 8kw

SUNPOK Inverter Three Phase With Mppt Solar Charge Controller Manufacturers 5kw 8kw

SUNPOK Three Phase Inverter

5kw 8kw Three Phase Inverter

Mppt Solar Charge Controller Inverter

Place of Origin:

China

Brand Name:

SUNPOK

Certification:

CE MSDS UN38.3

Model Number:

MPS-3500H

Contact Us
Request A Quote
Product Details
Product Name:
230V 5Kw 48V Off Grid Inverter
Rated Power:
5KW
Output Waveform:
Prue Sine Wave
Display:
LCD
Battery Voltage:
48V
Type:
DC/AC Inverters
Warranty:
2 Years
OEM & ODM:
Avaiable
System Voltage:
12v/24v/36v/48v Automatic Recognition
Highlight:

SUNPOK Three Phase Inverter

,

5kw 8kw Three Phase Inverter

,

Mppt Solar Charge Controller Inverter

Payment & Shipping Terms
Minimum Order Quantity
1 Unit
Price
USD 454 /Pcs
Packaging Details
Carton
Delivery Time
5-10 Day
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
5000 Unit Per Month
Product Description

Off-grid inverter | How Does It Work?
Are you in the market for an off grid inverter that can help you power your home or business? By combining leading solar technology, advanced inverter designs and reliable power storage, SunPok Energy provides the best off grid experience on the market.

SunPok's off grid inverters provide users with an energy efficient and reliable way to convert DC power from solar panels, batteries or other sources into AC power that can be used on almost any device. With a built-in smart grid, these inverters are able to track and monitor your energy usage, helping you make informed decisions on how you use the power you generate. SunPok's innovative designs are tailored to meet even the most extreme off grid conditions, making it the perfect choice for remote sites or locations with unreliable grid power.

What makes SunPok's inverter stand out from the rest? It's designed to deliver superior performance in off grid applications, with a wide range of features that make it perfect for a variety of power requirements. All of SunPok's inverters are IP65 waterproof and dust resistant, making them perfect for harsh outdoor conditions. The inverters come with various communication options and control capabilities, letting you easily monitor and control your energy usage.

If you're looking for a reliable, cost-effective power solution for your off grid energy needs, then the best off grid inverter from SunPok Energy is the perfect choice. With advanced features and reliable power storage, SunPok Energy's off grid inverters provide an outstanding performance while protecting your energy investment.


SUNPOK Inverter Three Phase With Mppt Solar Charge Controller Manufacturers 5kw 8kw 0


SUNPOK Off-Grid Off-Grid Inverter

Sunpok 5Kw single-phase high-frequency off-grid inverter is suitable for areas without power, nomadic areas, communication base stations, areas with unstable power, islands, border posts, scenic management offices, newsstands, battery packs for battery manufacturers, etc. Equipped with LED display, supports USB/RS232/RS485/Bluetooth/Dry-contact, compact design, and high-cost performance.



ModelMPS-3500HMPS-5500H
Rated Capacity3500W5500W
Peak Power3500VA5500VA
INPUT
Voltage230VAC
Selectable Voltage Range90-280VAC(for home appliances)
Frequency Range50Hz/60Hz(Auto sensing)
OUTPUT
AC Voltage Regulation (Batt.Mode)230VAC+5%
Surge power7000VA11000VA
Efficiency(Peak) PV to INV97%
Efficiency(Peak) BAT to INV94%
Transfer Time

10ms (for personal computers)
20ms(for home appliances)

Wave formPure Sine Wave
BATTERY & AC CHARGER
Battery Voltage24VDC48VDC
Floating Charge Voltage27VDC54VDC
Overcharge Protection31VDC61VDC
Maximum charge current80A80A
SOLAR CHARGER
MAX.PV Array Power5000W6000W
MPPT Range@ Operating Voltage120-500VDC
Maximum PV Array Open Circuit Voltage500VDC
Maximum Charging Current110A
Maximum Efficiency98%
PHYSICAL
Dimension.D*W*H(mm)472*298*129
Net Weight (kgs)9.5kg10.5kg
Communication Interface

RS485/RS232(Standard)
LCD remote/WIFI(Optional)

OPERATING ENVIRONMENT
Humidity5% to 95% Relative Humidity(Non-condensing)
Operating Temperature0°C to 55°C
Storage Temperature-15°C to 60°C



SUNPOK Inverter Three Phase With Mppt Solar Charge Controller Manufacturers 5kw 8kw 1


Features

Efficient power generation with higher income:

1.5 times overload output (200ms), resist the impact of instantaneous load

Wide voltage input range, early start and late stop, longer lasting power generation

Photovoltaic controller power upgrade can be connected to 5kW

MPPT has a wide voltage range and can adapt to various crystalline silicon components

Support mains bypass fast charging

Intelligent protection, simple operation, and maintenance:

Various gear charging voltages, adaptable to different batteries

Multiple working modes: photovoltaic priority/mains power priority/battery priority

LCD can be externally introduced to meet the monitoring needs of different customers

Non-linear loads can be connected

Safe and reliable, comprehensive peace of mind:

Diverse communication methods, support USB/RS232/RS485/Bluetooth/dry contact

Smart battery charger design to optimize battery performance

Mobile phone/computer intelligent monitoring, more convenient operation anytime and anywhere
